Flame 27.5" Mountain Bike MTB

Flame 27.5" Mountain Bike

Geometry

Key Features

• Tough and lightweight 6061 aluminium alloy frame
• SR Suntour XCE Suspension Fork 27.5", XCE, travel 100mm
• Tektro M280 MECHANICAL disc brakes
• Shimano Tourney 24(3x8) speed drivetrain.
• Double-wall rims
• Tyres: 60Tpi 27.5*2.25
• Kenda Tubes 27.5*2.25

Specification

SKU	SM:HBA24Y15038A MD:HBA24Y17038A LG:HBA24Y19038A	Saddle	VELO MTB   VL-3889
Season	2024	Seatpost	Horacio alloy 30.4 x 350mm
Wheel Size	27.5" (650b)	Stem	Horacio Alloy Foged Stem, Black, 31.8mm
Colour	Red / Black	Shifters	Shimano TX800 EZ-Fire 24-speed
Frame	6061 aluminium alloy	Tyres	MTB 27.5*2.25 60Tpi
Fork	SR Suntour XCE Suspension Fork 27.5", XCE, travel 100mm	Tubes	Kenda 27.5*2.25 A/V
Groupset Brand	Shimano Tourney	Speeds	3 x 8
Rear Gears	8 Speed	Rider Weight Limit	The maximum weight limit for our adult bikes is 100kg. This includes the rider weight plus any bags accessories basket contents or backpacks etc.
Front Gears	Triple	Derailleur Rear	SHIMANO Shimano TX800
Brake Type	Mechanical Disc Brake	Grips	Rubber Grips, Black
Front Travel	100mm	Handlebar	Horacio alloy Handlebar, Dia: 31,8mm, 700mm, 6° Backsweep, 20mm Rise, Sanblasted Black
Brakes	TEKTRO MECHANICAL MD-M280 DISC BRAKE ROTOR :160mm	Headset	NECO Semi-Integrated
Cassette	SHIMANO HG200 8-SPEED 12-32T INDEX CASSETTE	Hubs	Alloy disc specific MTB with quick release
Chain	KMC Z7 1/2" x 3/32" 116L	Bottom Bracket	NECO Sealed Bearing
Crankset	Prowheel MA-AC49 Alloy 42/34/24T 170mm	Pedals	Alloy MTB
Derailleur Front	SHIMANO Shimano TX800	Rims	27.5*14G, DOUBLE WALL
Derailleur Rear	SHIMANO Shimano TX800	Saddle	VELO MTB VL-3889
Grips	Rubber Grips, Black	Seatpost	Horacio alloy 30.4 x 350mm
Handlebar	Horacio alloy Handlebar, Dia: 31,8mm, 700mm, 6° Backsweep, 20mm Rise, Sanblasted Black	Stem	Horacio Alloy Foged Stem, Black, Φ28.6mmXΦ31.8mm
Headset	NECO Semi-Integrated	Shifters	Shimano TX800 EZ-Fire 24-speed
Hubs	Alloy disc specific MTB with quick release	Tyres	MTB 27.5*2.25 60Tpi
Bottom Bracket	NECO Sealed Bearing	Tubes	Kenda 27.5*2.25 A/V
Pedals	Alloy MTB	Speeds	3 x 8
Rims	27.5*14G, DOUBLE WALL	WEIGHT	14.4 kg (27.5" S) 14.4 kg (27.5" M)/14.4 kg (27.5" L)

SKU	SM:HBA24Y15038A MD:HBA24Y17038A LG:HBA24Y19038A
Season	2024
Wheel   Size	27.5"   (650b)
Colour	Red / Black
Frame	6061 aluminium   alloy
Fork	SR Suntour XCE Suspension Fork 27.5", XCE, travel 100mm
Groupset   Brand	Shimano Tourney
Rear   Gears	8 Speed
Front   Gears	Triple
Brake   Type	Mechanical Disc   Brake
Front   Travel	100mm
Brakes	TEKTRO   MECHANICAL MD-M280 DISC BRAKE ROTOR :160mm
Cassette	SHIMANO HG200   8-SPEED 12-32T INDEX CASSETTE
Chain	KMC Z7   1/2" x 3/32" 116L
Crankset	Prowheel   MA-AC49 Alloy 42/34/24T 170mm
Derailleur   Front	SHIMANO Shimano   TX800
Derailleur   Rear	SHIMANO Shimano   TX800
Grips	Rubber Grips,   Black
Handlebar	Horacio alloy   Handlebar, Dia: 31,8mm, 700mm, 6° Backsweep, 20mm Rise, Sanblasted Black
Headset	NECO   Semi-Integrated
Hubs	Alloy disc   specific MTB with quick release
Bottom   Bracket	NECO Sealed   Bearing
Pedals	Alloy MTB
Rims	27.5*14G,   DOUBLE WALL
Saddle	VELO MTB   VL-3889
Seatpost	Horacio alloy   30.4 x 350mm
Stem	Horacio Alloy   Foged Stem, Black, 31,8mm
Shifters	Shimano TX800   EZ-Fire 24-speed
Tyres	MTB 27.5*2.25   60Tpi
Tubes	Kenda 27.5*2.25   A/V
Speeds	3 x 8
Rider   Weight Limit	The maximum   weight limit for our adult bikes is 100kg. This includes the rider weight   plus any bags accessories basket contents or backpacks etc.
Derailleur   Rear	SHIMANO Shimano   TX800
Grips	Rubber Grips,   Black
Handlebar	Horacio alloy   Handlebar, Dia: 31,8mm, 700mm, 6° Backsweep, 20mm Rise, Sanblasted Black
Headset	NECO   Semi-Integrated
Hubs	Alloy disc   specific MTB with quick release
Bottom   Bracket	NECO Sealed   Bearing
Pedals	Alloy MTB
Rims	27.5*14G,   DOUBLE WALL
Saddle	VELO MTB   VL-3889
Seatpost	Horacio alloy   30.4 x 350mm
Stem	Horacio Alloy   Foged Stem, Black, Φ28.6mmXΦ31.8mm
Shifters	Shimano TX800   EZ-Fire 24-speed
Tyres	MTB 27.5*2.25   60Tpi
Tubes	Kenda 27.5*2.25   A/V
Speeds	3 x 8
WEIGHT	14.4 kg   (27.5" S) 14.4 kg (27.5" M)/14.4 kg (27.5" L)

Support & Assembly

FAQs

What should I do after receiving my bicycle?



Downloads

Front Derailleur Adjustment

Rear Derailleur Adjustment

Operator's Guide for Adjusting Shimano Derailleurs



Worry-Free Minimal Assembled

Before shipping your bike to you, we conduct a thorough inspection and fine-tuning in our warehouse, ensuring minimal issues and a hassle-free assembly experience.

All our mountain bikes come 85% assembled, and we provide tools and easy-to-follow tutorials to help you with the final assembly. If you have any questions, please do not hesitate to contact our customer service team.

While we are currently unable to provide assembly services to all customers, we do offer door-to-door assembly services in limited areas. To learn more, please reach out to us at info@horaciobikes.com.au.

Downloads

Assembly and Installation Guide

Shipping & Warranty

We take pride in the quality and craftsmanship of our bicycles, and we are committed to ensuring your satisfaction with your purchase. We offer up to Lifetime Warranty on select parts. Terms and conditions apply. Click here to see more details.

Dispatch

When your order is confirmed, we will advise you of the expected dispatch date of your order. All orders received by 4 pm AEST will usually be dispatched the following business day.

Shipping Fee

For most areas in Brisbane, the Gold Coast and Ipswich, we offer local delivery with assembly service. For other metro areas in Australia, the bicycle shipping cost is from $39.99 per bike. To check if your shipping rate please refer to the product page or checkout page. Please contact us by email if you can't get your shipping rate automatically.

Turnaround Time

Local Delivery will take around 2 to 5 working days.

For other metropolitan areas, it would take around 2-7 days for the shipping.
